3-Axle Side Dump Semi Trailer
Product Overview
The 3 Axle Side Dump Semi Trailer is engineered for heavy-duty bulk material transportation where fast unloading and high productivity are essential.
Unlike conventional rear dump trailers, the side tipping system allows unloading without requiring large rear clearance, making it ideal for confined working environments such as tunnels, mines, construction sites, and industrial plants.
Manufactured with high-strength Q345B steel and a reinforced chassis, the trailer offers excellent load capacity, superior structural durability, and a long service life. The optimized hydraulic lifting mechanism ensures smooth and reliable dumping while reducing operating time and labor costs.
Its robust design, customizable configurations, and low maintenance requirements make it an ideal choice for dealers, fleet owners, and transportation companies worldwide.
Key Features
- Efficient Hydraulic Side Dumping System
The hydraulic side tipping mechanism enables quick, stable, and efficient unloading from one side without requiring rear dumping space.
This significantly reduces unloading time while improving productivity on construction sites, mines, and material handling operations.
- Heavy-Duty Structural Design
Built with high-strength Q345B carbon steel and reinforced cross members, the trailer delivers exceptional durability under continuous heavy-load operations.
The wear-resistant body is suitable for transporting abrasive materials such as stone, gravel, coal, and ore.
- Stable & Anti-Rollover Performance
The optimized center of gravity, reinforced chassis, and precisely engineered dumping angle provide excellent stability during unloading.
This minimizes rollover risks and ensures safer operation on uneven or sloped terrain.
- Large Payload Capacity
Available with 3-axle configurations, the trailer supports payload capacities from 30 to 50 tons, meeting various transportation requirements for mining, quarrying, and construction industries.
- Reliable Hydraulic System
Equipped with high-quality multi-stage hydraulic cylinders and hydraulic components, the lifting system provides powerful, smooth, and reliable tipping performance with low maintenance costs.
- Flexible Customization
Body length, box height, axle brands, suspension types, hydraulic systems, and painting colors can all be customized according to customer requirements and local road regulations.
Specifications
| Product Name | Side Dump Semi Trailer |
| Payload Capacity | 30–50 Tons |
| Axles | 3 Axles, 13T FUWA / BPW |
| Tires | 12 pcs, 12R22.5 |
| Overall Dimensions | 12,500–16,000 × 3,000 × 1,550 mm (Customizable) |
| Tare Weight | Weight |
| Axle Spacing | 1,310 mm |
| Rims | 8.5-20 / 9.0-20 |
| Suspension | Leaf Spring Suspension / Air Suspension |
| Brake System | Dual-line Pneumatic Brake System with WABCO Emergency Relay Valve |
| Main Beam | Height 500 mm, Q345B Carbon Steel |
| Hydraulic System | High-pressure Multi-stage Hydraulic Cylinder |
| Dumping Angle | 45°–70° |
| Kingpin | 2" or 3.5", JOST Brand |
| Landing Gear | 28 Tons, Two-speed Manual Operation |
| Electrical System | 24V, 7-way Socket |
| Painting | Customer Customized |
| Tool Box | One Standard Tool Box |
Applications
- Mining Industry
Suitable for transporting coal, iron ore, copper ore, limestone, aggregates, and other mining materials.
The side dumping function enables fast unloading in narrow mining roads and underground tunnels.
- Construction Projects
Ideal for transporting sand, gravel, crushed stone, asphalt materials, and construction waste.
Quick unloading greatly improves project efficiency.
- Quarry Operations
Designed for continuous transportation of rocks, aggregates, and heavy bulk materials between quarry sites and processing plants.
- Agriculture
Suitable for transporting grain, fertilizer, animal feed, and other agricultural bulk materials.
- Infrastructure & Industrial Material Transport
Widely used in highways, railways, ports, hydropower projects, and industrial material transportation requiring high efficiency and heavy payload.
Customization & Procurement Information
- Customization Options
- Trailer dimensions
- Body volume and height
- Payload capacity
- Hydraulic cylinder brand
- Axle brand (FUWA/BPW/SAF)
- Suspension type (Mechanical or Air)
- Tire brand and specifications
- Brake system
- Painting color
- Toolbox configuration
- Electrical system
OEM & ODM
Professional OEM and ODM manufacturing services are available.
- MOQ: 1 Unit
- Production Time: Approximately 15–30 working days after deposit and drawing confirmation.
- Delivery Time: Approximately 20–45 working days depending on destination.
- Packaging: Suitable for Ro-Ro shipping, bulk cargo vessel transportation, or container shipment (when applicable). Anti-rust wax coating and protective wrapping are available upon request.
uality & Certification
Quality Inspection
Every trailer undergoes strict quality inspections, including:
- Raw material inspection
- Welding quality inspection
- Hydraulic system testing
- Brake system testing
- Electrical system inspection
- Full vehicle loading and road testing
- Certifications
Available certifications include:
- ISO 9001
- CCC
- COC
- CE (Optional)
- Other destination-country certifications upon request
- Documents Supplied
- Vehicle Conformity Certificate
- Quality Inspection Report
- User Manual
- Warranty Documents
- Component Certificates
FAQ
- What materials is the side dump semi trailer suitable for?
It is mainly designed for transporting sand, gravel, stone, coal, ore, aggregates, construction waste, fertilizer, grain, and other loose bulk materials.
- What is the standard payload of the 3 axle side dump semi trailer?
A: The standard payload ranges from 30 to 50 tons, and higher capacities can be customized according to customer requirements.
- Can the trailer be equipped with air suspension?
Yes. Both mechanical leaf spring suspension and air suspension are available.
- What hydraulic system do you use?
We use high-quality multi-stage hydraulic cylinders with reliable hydraulic components, providing stable lifting performance and long service life.
- Can the trailer dimensions be customized?
Yes. Trailer length, body height, body thickness, hydraulic configuration, axle brand, suspension, and other specifications can all be customized to meet local transportation regulations and operating conditions.
