Curtain Side Semi Trailer
Product Description
Flexible Curtain-Side Design Allows Fast Side Loading and Unloading
The sliding PVC curtain can be quickly opened or closed, making it easy to load cargo from the side using forklifts, especially in areas where rear access is limited.
Ideal for Palletized and General Cargo Transport Across Long Distances
Designed for high-volume logistics operations, it can carry goods including packaged products, consumer goods, and industrial materials in regional or cross-border transport.
Lightweight Yet Durable Structure Ensures Better Payload Efficience
Built with a steel or aluminum frame and reinforced roof, the trailer maintains structural integrity while keeping overall weight low to maximize cargo capacity per trip.
Curtain System with Buckles and Tensioners Keeps Cargo Protected
The curtain is secured tightly using vertical buckles and tensioning rails, preventing wind or rain from entering, while keeping cargo stable and shielded during transport.
Modular Cargo Space with Customizable Partitioning Solutions
Floor pre-embedded tracks compatible with cargo nets/partitions/straps for quick fastening. Customizable with or without side post structure.
Efficient for Drop-and-Hook or Fast Turnaround Logistics Operations
Popular in logistics and 3PL services, the side curtain trailer supports quick loading cycles, helping reduce downtime at loading docks and improve transport efficiency.
Specifications
| Parameter | Details |
| Loading Capacity | 30 ~ 100 ton |
| Axle | 2/3/4 axle, BPW/FUWA |
| Dimensions | 12500*2500*3550mm (can be customized) |
| Rim | 9.00*22.5 / 8.00-20/8.5-20 |
| Suspension | Mechanical suspension or Air suspension |
| Leaf Spring | 90(width)mm*13(thickness)mm*10 layer |
| King pin | Jost brand 2.0 or 3.5 inch |
| Landing Gear | Jost brand, fuwa brand, other brand |
| Main beam | Height Q345 carbon steel |
| Chassis | Upper 14mm, lower 16mm, middle 8mm |
| Bottom Platform | 3mm chequered steel plate |
| Brake chamber | 6 wabco relay valve, T30/30+T30 spring brake chamber, 2 units of 45L air tank |
| Electrical System | Voltage: 24v; Receptacle: 7 ways (7 wire harness) |
| Tool Box | One piece 1m * 0.5m * 0.5m (size can be customized) |
| Side curtain material | Polyester, Nylon, PVC |
| Sliding rail | Electric/Manual |
| Painting | All color will be available/Side curtain patterns can be customised |
Trusted Manufacturer Supporting Specialized Transport Solutions
As one of the recognized semi trailer brands with global reach, Fuyuan combines advanced manufacturing, rigorous quality control, and export-oriented standards to deliver dependable trailer solutions worldwide. Beyond standard logistics configurations, we also support customized designs and special transportation services for non-standard or complex cargo requirements that require specialized engineering and tailored trailer features.
With strong OEM capabilities, stable production capacity, and customer-oriented service, Fuyuan is committed to providing efficient, durable, and cost-effective transportation solutions for logistics hubs, freight forwarders, and large fleet operators.
